DMM Director Yoke Rope Spacer for Clean Rigging Setups

Description

DMM Director Yoke Rope Spacer

Compact termination carabiners for every application.

The Director Yoke is a compact termination connector designed to load in the strongest orientation. Ideal for lanyards, these lightweight, versatile and strong carabiners are easy to handle and can reduce the overall length of a system.

The Director Yoke features a textile friendly, configurable eye, an extra short gate, a generous curve in the loading area and healthy gate openings. They can be retro fitted onto pre-stitched or swaged lanyard components or used in conjunction with DMM Linkits to form super short connectable systems. When used in conjunction with the DMM Director Swivel Boss, it forms the ultimate swivelling, pivoting double connector.

Choose between a rope or webbing spacer to give optimised textile compatibility.

FEATURES

• Compact, lightweight and versatile.
• Designed to ensure major axis loading.
• “Rhino horn” ensures device remains in loading area.
• Incorporates DMM’s shortest gate.
• Low overall length well suited to restricted height scenarios.
• Compatible with existing range of DMM Linkit lightweight rigging components.
• Patented features.
• Hot forged and CNC machined.

Locking gate types

Screwgate

Manual locking gate requiring screwing/unscrewing of the barrel to lock/unlock.

Kwiklock

Auto-locking gate requiring two distinct actions to open.

Locksafe

Auto-locking gate requiring three distinct actions to open.

Durolock

Auto-locking gate requiring four distinct operations to open. Force must be maintained throughout or the gate returns to safe (locked).

Kwiklock ANSI

Same gate action as Kwiklock but the connector is also required to exceed 16kN in minor axis, side load and gate face tests.

Locksafe ANSI

Same gate action as Locksafe but the connector is also required to exceed 16kN in minor axis, side load and gate face tests.

Tech Specs

Product Name	Product Code	Dimensions	Weight	MBS (Major Axis)	MBS (Minor Axis)	MBS (Gate Open)	Gate Opening	Certification
Director Yoke Screwgate Rope Spacer	A622RS	64 x 98mm	68g	25kN	N/A	9kN	17mm	EN12275:2013 T EN362:2004 T
Director Yoke Locksafe Rope Spacer	A627RS	64 x 98mm	76g	25kN	N/A	9kN	16mm	EN12275:2013 T EN362:2004 T
Director Yoke Kwiklock Rope Spacer	A623RS	64 x 98mm	75g	26kN	N/A	9kN	17mm	EN12275:2013 T EN362:2004 T
Director Yoke Screwgate Web Spacer	A622WS	64 x 98mm	68g	25kN	N/A	9kN	17mm	EN12275:2013 T EN362:2004 T
Director Yoke Locksafe Web Spacer	A627WS	64 x 98mm	76g	26kN	N/A	9kN	16mm	EN12275:2013 T EN362:2004 T
Director Yoke Kwiklock Web Spacer	A623WS	64 x 98mm	75g	26kN	N/A	9kN	17mm	EN12275:2013 T EN362:2004 T
